Learn the benefits that Super Gel 9AO has to offer, including thermal conductivity and dimensional stability as design engineers, John and Ted, work to develop their electronic component.
With the help of a Master Bond representative, they discover that Super Gel 9AO’s softness and retrievability is exactly what they need.
Two component, thermally conductive urethane modified epoxy gel-like system
Key Features
- Cures to a low Shore A hardness
- Impressive thermal conductivity
- Relatively easy to remove
- Excellent for potting and encapsulation
- Convenient handling & curing at room temperature
- Robust electrical insulation properties
Product Description
Master Bond Super Gel 9AO is a two component, urethane modified epoxy system that cures at room temperature with resounding softness and dimensional stability. Additionally, it possesses compelling thermal conductivity and electrical insulation values. Its exceptional softness optimizes the ability to retrieve components if needed. This can be accomplished with a sharp knife or razor blade. It has first class handling properties: an easy to use two to one mix ratio by weight, good flow and a long working life. It has low exotherm enabling it to be cast many inches in depth. Its hardness is exceptionally low, about 20-30 Shore A. The combination of its easy handling and cured properties enables this versatile system to be used in a variety of applications, especially the encapsulation of sensitive electronic parts and related components. It is particularly useful in those applications where softness and thermal conductivity are desirable. Additionally, the extraordinary softness allows it to be easily repairable and confers it with unsurpassed thermal cycling and thermal and mechanical shock resistance.
Super Gel 9AO bonds well to an array of substrates, such as metals, glass, ceramics and many rubbers and plastics. It has a remarkably long working life of 6-8 hours depending on the mass that is mixed (the smaller the mass, the longer the working life). It has good resistance to water and oils. The service temperature range is -100°F to +200°F. The color of both Parts A and B are light gray. This multi-functional system is widely used in the aerospace, electronic, optical, electro-optical and other specialty industries where the unique blend of properties, discussed above, is needed.
Product Advantages
- Easy handling; two to one mix ratio by weight or volume; low to moderate viscosity
- Very low exotherm; favorably long working life
- Wonderful softness and resilience, yet solid dimensional stability
- Easily repairable; widely used for retrieving components
- Often used in conjunction with sensitive electronic components
- Admirable thermal conductivity and striking electrical insulation properties
Industrial Certifications
Meets EU Directive 2015/863
Packaging
Cans
Double Barrel Cartridge
Gun Applicator
Pails
Syringes
Super Gel 9AO is available is various sizes and units to accommodate customer's needs.
